Using electronic harmonization with woodwinds

In a recent recital I performed my own arrangement of Ravel’s Boléro for multiple woodwinds soloist using electronics, with piano and snare drum. I used electronics to try to approximate some of Ravel’s harmonies (and timbres), and used what in my mind are three different techniques, which I’ll try to outline here.

In performance, I used the BOSS GT-1000CORE guitar multi-effects unit to do most of the heavy lifting. I did find that it had difficulty tracking my flute playing (though, surprisingly, it did better with piccolo), so I used an Electro-Harmonix Pitch Fork + to assist with that instrument in particular. I also used a BOSS SY-200 to try to create some non-woodwind tone colors. There are plenty of other equipment options that can achieve similar effects, but you’re on your own to read the manuals.

All of this was done with a microphone rather than pickups, which was less complicated for quick instrument switches, but did make it difficult to get relatively isolated woodwind sounds into the electronics, which ultimately caused problems with the audibility of some of the electronic sounds.

The warts-and-all live performance is available on my YouTube channel, but I’ll provide some clearer, isolated examples here. For rehearsal numbers in the orchestral score, I’m referring to the Durand Edition on IMSLP.

Technique 1: parallel intervals

At rehearsal mark 8 in the score, horn and celeste play the A theme in octaves, with two piccolos playing in parallel a perfect fifth and a major tenth above the celeste’s highest octave, perhaps in imitation of a pipe organ’s mixture stop.

To achieve this harmony with electronics, I played the upper piccolo part “live,” and routed the piccolo’s sound into the GT-1000CORE where I split it into two separate signal paths. One got transposed down using a digital pitch shifter to create the second piccolo part. The other got transposed down to the melody pitch and split into octaves, then routed through the SY-200 to turn the sound into something vaguely celeste-like.

Since the intervals are strictly parallel, this is a pretty straightforward use of pitch shifting: whatever note I play on the piccolo gets transposed to the specified intervals.

Technique 2: smart harmonization

At rehearsal mark 16, a thickly-orchestrated ensemble of woodwinds, brass, and strings plays the A theme in harmony. I opted to play this portion on soprano saxophone, thickened and harmonized with a synthesized string section.

Since the harmony in this section is largely diatonic, I used the GT-1000CORE’s smart harmonizer. I added voices a diatonic fourth and diatonic sixth below in the key of G (like a first-inversion triad), which tracks with the notes in the first part of the theme. But there’s a moment in the first part that uses F-natural instead of F-sharp, and the second part of the melody uses F-naturals exclusively, so I used the unit’s footswitches to change to the key of C major as needed. I routed all of this through the SY-200 to change the three soprano saxophones into a string section sound, with the “live” soprano remaining audible in the room.

For the key switching, I set one footswitch as a “momentary” switch, so it changes the key just while I’m pressing it, and another as a “toggle” switch, so I can press and release it and the key remains changed. This gives me some helpful options for live performance.

Technique 3: smart harmonization with custom scales

The smart harmonizer works well out of the box as long as you want to use notes of a major scale (or mode thereof), but at rehearsal mark 15 Ravel’s harmonization is more complicated than that. Luckily, the GT-1000CORE supports smart harmonization with custom “scales.” What this really means is that I can tell the unit that any time I play a certain pitch, it should add one or more pitches that I can specify arbitrarily. I can add whatever pitches I like to each note of the chromatic scale.

I chose to play this section on clarinet, using the electronics to turn it into a 3-part clarinet section. During the first phrase, the melody pitches are harmonized in a consistent way: every time there’s a melody concert B-flat it’s harmonized with a G and an E, every time there’s a melody C it’s harmonized with an A and an F, every time there’s a melody E it’s harmonized with a C and a G, and so forth. I can just tell the effects unit which harmony notes to add to each melody note.

But things change in the first half of the second phrase: melody B-flat is now harmonized with G and D, and C is now harmonized with A and E. To accommodate this I have to create a second custom “scale,” and use a footswitch to activate it at the right time. To finish the second phrase requires a third scale, engaged with another footswitch.

Because of the flexibility of the custom scale system, I can recreate harmonies that use a variety of intervals. With a little analysis I can figure out where the scale changes need to be (basically anywhere a given melody pitch is harmonized in a new way).

Additional thoughts

There are some limitations to using pitch shifters and harmonizers, depending on your equipment. Each virtual pitch shifter and harmonizer in the GT-1000CORE can only add two voices, though by (virtually) splitting the audio signal into multiple paths and passing each through its own shifter/harmonizer I can build thicker chords.

When trying to reproduce specific harmonies written by a composer, there may be some decisions to make to balance accuracy with practicality. Serendipitously, most of Ravel’s harmony translated fairly easily to the effects unit’s capabilities. But there were a few spots where I decided that certain chord voicings were close enough, and that I didn’t need to complicate things with one more custom scale plus the corresponding onstage footwork.

As I’ve mentioned previously, I’m more interested in electronic effects that give my woodwinds new capabilities, like polyphony, than in just adding some distortion or echo (though those are also fun). Enjoy!

Recital videos, August 2023

I’m pleased to share videos from my recent Delta State University faculty recital.

Favorite blog posts, July 2023

See the woodwind blogs I’m following, and suggest others!

Favorite blog posts, June 2023

See the woodwind blogs I’m following, and suggest others!

Favorite blog posts, March 2023

See the woodwind blogs I’m following, and suggest others!

Experiments with electric woodwinds

I’ve been having fun with woodwinds enhanced with pickups or microphones. (If you’re interested in natively-electronic instruments like wind controllers, I’ve written about those elsewhere.)

I still have a lot to learn about working with electronics. But here are a few observations in case anyone finds them helpful.

Which instrument(s) to use? I find lower-pitched instruments to be more fun, since they can provide convincing bass lines. Electronics can pitch a high instrument down, of course, but I haven’t had the success I would like making this sound good. So far I’ve installed pickups into a bassoon bocal, a bass clarinet neck, and an English horn bocal. I’ve used microphones for other instruments.

Which gadgets to use? I’m personally using the Little-Jake pickups, a looper, and a multi-effects unit. When I started getting into effects pedals, I found it alarmingly easy to accumulate quite a few. This was a good and inexpensive way to get started. But I quickly discovered that it was becoming unwieldy to try use use more than a few in performance (I literally had to walk back and forth across the stage to get to them all). A multi-effects unit turned out to be much more practical, with a few foot switches I can configure to operate a large number of effects. (I’m currently using one by Boss.) It takes a little more advance setup than individual pedals, but greatly simplifies the onstage footwork. And I was pretty easily able to sell off the individual pedals to fund the purchase.

Which effects to use? I think the best-known guitar-type effects are distortion, delay/echo, and reverb. Those are fun to play with, but I’ve become more interested in ones I can use to give my instruments new capabilities, rather than just give their sounds a little grittiness or echo. For example, smart harmonizers (which add harmony lines based on a selected key) and pitch shifters (which add harmony lines based on selected intervals) make my instruments polyphonic, a significant upgrade for a woodwind player. And a looper, or even a cleverly-used delay, can create counterpoint.

Here are a few examples of my experiments:

There are eight audio tracks here, but each one is performed “live.” I’m trying to somewhat replicate sounds from the original song: two vocal parts, two guitars, piano, electric piano, and electric bass, plus various synthesizer lines that I’ve consolidated into one. I’m using harmonizers and pitch shifters on the “guitars” and “keyboards” to perform chords in real time. I’m also pitch shifting the “bass” to let the English horn play much lower than its natural range.
I’m using a harmonizer here similarly to how I used it in the English horn video, but you can get a better view of what that involves footwork-wise. I’m using several carefully-programmed footswitches to change the harmonizer’s parameters as I go, in order to get the chromatic harmony that I want. On the A sections of the tune, I’m also using a pitch shifter to double the melody up an octave. The separate bass part that starts at about 0:28 uses pitch shift to drop the sound down an octave.
This is an example of using a looper (the red unit) to layer multiple lines, while using the multi-effects unit (black) to do real-time harmony and some other things. The “bass” part, shifted down two octaves, isn’t as convincing as I would like (you may have to use earphones to hear it).
Here’s a live-performance example using looper plus multi-effects unit.
Here I’m using the multi-effects unit to perform the melody “call” and harmonized “response” (unfortunately distorted and too soft), and using the looper to provide backing for an improvised solo.
Here’s an attempt to replicate one of Paul Hanson’s incredible electric bassoon “hocket” performances (I fell a bit short). The technique uses a delay to create a single well-timed echo, with the result being that I’m only playing every other note you hear; the in-between notes are echoes of previously-played ones. To get the full effect, check out Paul’s video.
This one you can actually buy sheet music for; the arranger, Melissa Keeling, provides parameters for using a harmonizer and a delay (which could be separate pedals or functions of a multi-effects unit).

Favorite blog posts, January 2023

See the woodwind blogs I’m following, and suggest others!

Favorite blog posts, December 2022

See the woodwind blogs I’m following, and suggest others!

What kind of ligature should I get?

I’m on record as believing that clarinet and saxophone ligatures make little if any actual difference in how you sound. You’re welcome to disagree, but you might want to watch Michael Lowenstern’s video about it first.

So, assuming the ligature has little direct influence on sound, what is the best kind to buy?

Consider the humble fabric-type ligature:

Fabric-type clarinet and saxophone ligatures

They can be made of fabric or various other flexible materials. Fake-leather materials are popular.

Here are their advantages over most other ligatures:

  • Generally inexpensive, although there are pricier versions available if paying more makes you feel better
  • Relatively easy to fit to even unusual mouthpieces and reeds, since they are flexible
  • Durable: I still have and use one I bought in high school
  • Not easily damaged: can be dropped, stepped on, or otherwise battered with little if any ill effect
  • Won’t dig into or otherwise damage reeds or mouthpieces
  • More expensive than an actual shoelace, but quicker and easier to install
  • Ambidextrous: many of the popular inexpensive ones can be switched for left- or right-handed screw tightening
  • Usually just one screw to tighten, so 50% less tightening/loosening time than the many other kinds of ligatures that have two screws
  • Available: no waiting lists or custom-building, easily purchaseable from just about any brick-and-mortar or online band-instrument retailer

I have a number of fancy and expensive ligatures that various teachers required I buy over the years of my education, including some plated in actual gold. They don’t outperform my fabric-type ones in any meaningful way. You may still see them in my performance videos, etc., as I am still trying to get my money’s worth out of them. When they break or wear out, I’ll replace them cheaply and easily with good reliable fabric ones.

Get a good, reliable, no-nonsense ligature to hold your reed in place, and happy practicing!

Why doesn’t my new mouthpiece work?

a person s hand holding saxophone mouthpiece

So you bought a new mouthpiece! How exciting. But wait—it’s not playing as well as you hoped. Maybe it squeaks, or some (or all) notes don’t come out very well, or the tuning is weird. Let’s consider some possible reasons why:

  • First, it’s always a good idea to review the fundamentals of tone production: breath support, voicing, and embouchure. Those things probably didn’t really change when you got a new mouthpiece, but maybe the old one was more forgiving of some weaknesses in your technique, and the new one is revealing those issues.
  • A new mouthpiece is likely to require a different reed than the old mouthpiece. Try some harder or softer reeds and see if your results change. In general, a mouthpiece with a larger tip opening tends to like a softer reed, and a smaller opening works better with a harder reed. But it’s more complicated than that, and the only way to really know which strength, cut, brand, etc. will work best is to try them out. (Some mouthpiece makers do suggest reeds that go well with their mouthpieces, but your results may vary.)
  • Also: even if your new mouthpiece is compatible with the reeds you have been buying, ones that you previously used on the old mouthpiece may have kind of molded to the old mouthpiece. Try some fresh ones.
  • Not all mouthpieces are created equal, even mouthpieces of the same brand and model. This can be due to hand-finishing or other manufacturing variables. It’s possible that the one you got isn’t as good as the one that your friend or teacher or favorite professional player uses. If possible, it’s worth trying several before you pick one. And especially with older or used mouthpieces, they can warp or otherwise change shape in small ways, and that can change their playing characteristics and ability to mate well with a reed.
  • Let’s consider one more hard truth: if you bought a mouthpiece never having played on it (or at least one like it) before, you may have picked something that just isn’t going a good match for you. It’s easy to get caught up in the promises in advertising copy or on product websites, or to assume that your favorite player’s mouthpiece will be suited to your equipment and playing style. Some mouthpieces are made for extreme or unusual reed choices, embouchures, or playing situations, but most players benefit from a relatively middle-of-the-road mouthpiece. And, of course, some mouthpieces just aren’t as good as advertised at all. Your best bet might be to return or sell the new mouthpiece, and invest instead in lessons with a good teacher who can either guide you in a better-informed purchase, or help you get the results you want out of a mouthpiece you already have.

A good rule of thumb is that a mouthpiece can’t give you skills, talent, or creativity. It can only remove, or add, obstacles to tone production. Pick a mouthpiece that makes it easier for you to do what you do, and get some help from a qualified teacher if needed. Good luck!
