Rediscovering the clarinet’s left-hand sliver key

I think for many doublers the clarinet’s left-hand “sliver” key seems useless or problematic. For example, the sliver key is easy to press by mistake when intending to cover the middle and/or ring finger holes. And even when reaching for the sliver on purpose, it’s easy to accidentally cover part of the ring finger hole, producing an E-flat or B-flat that is flat and stuffy.

The left-hand sliver also lacks any real analogue on any of the other common woodwinds, so its use is a technique that doesn’t transfer easily from another instrument. Flutes, saxophones, and standard bassoons don’t have any key in that spot. The oboe has a trill key there, but its usage isn’t similar. Among the standard band/orchestral woodwinds, only the contrabassoon has a key positioned here that is used in a similar way to the clarinet family. Especially for saxophonists, the right-side fingering is much more familiar.

The Woodwind Fingering Guide (still the best fingering source on the web) lists three E-flat/B-flat fingerings in its standard clarinet fingering chart, with only the right-side-key fingering marked as “basic.” The left-hand-sliver fingering is described as a “Chromatic and trill fingering,” to “use in combination with D4 [D below the staff] and A5 [A above the staff].” (The “one and one” fingering using both index fingers is also listed, though it might perhaps be better relegated to the “alternate” fingering chart.)

Occasionally I’ve run across the attitude that the sliver key could perhaps be removed or wedged shut to prevent accidental venting. I think this would be a waste, and all clarinetists of an intermediate level or higher should get used to using this key as an equal partner with the right hand key—not merely as an alternative for rare occasions.

Here are a couple of examples from well-known solo repertoire where the left-hand sliver makes sense:

From Debussy, Première Rhapsodie. Click to enlarge.

In this example from Debussy, the E-flat occurs four times, each time preceded by E-natural, and followed in three cases by D—this is the aforementioned “chromatic” usage. Among the three most-common E-flat fingerings, the sliver is clearly the best technical choice here. While one-plus-one works equally well (from a technical standpoint) moving from E to E-flat, E-flat to D is compromised by having  to move two fingers, each on a different hand, each moving in a different direction; the intonation issues of one-plus-one further complicate its use. The right-hand-side fingering is less hairy, but does involve moving fingers on both hands simultaneously (a maneuver which should, of course, be possible, but which carries unnecessary risk of mistiming).

From Finzi, Five Bagatelles. Click to enlarge.

This excerpt from the first of Finzi’s Five Bagatelles highlights some other use cases. In the second measure of rehearsal number 4, a well-trained clarinetist will use the two lowest right trill keys for G-flat, which would make a transition to one-plus-one or right-side E-flat unnecessarily awkward, particularly since the E-flat then moves right back to G-flat. The sliver key allows for crisp, tidy finger movements. In the last two measures of this excerpt, the sliver key again constrains the fingers to similar motions in adjacent fingers of a single hand.

If you are new to the use of the left-hand sliver (or just a little rusty), I suggest conditioning its use for both E-flat and B-flat with slow, deliberate scale practice. Start with the chromatic scale and B-flat major, then look for appropriate places to use it in other major and minor scale material.

Similar Posts

  • Avoiding clarinet undertones: published techniques

    Clarinet “undertones” or “grunts” are the unpleasant low sounds that happen usually at the beginning of tongued upper-clarion-register notes (about written G to C, above the staff). They are the lower register speaking out of turn—a clarion G’s undertone, for example, is the chalumeau C.

    Fine clarinetists can more or less eradicate the problem, but there isn’t a lot of consensus or clarity among clarinetists about how exactly this is done. I checked some published clarinet wisdom that I had at hand, to see what some of the experts say about what causes undertones, or how to eliminate them. Here are the results:

    To prevent clarinet undertones in the upper clarion register…

    This listing isn’t comprehensive, so I welcome submissions if you can point me toward published sources. And in many cases I have done some interpreting of the authors’ intents. (Julie DeRoche, for example, lists a number of embouchure specifics in her article, which I have reduced to “Ensure correct, stable embouchure formation.”) If you are one of the authors, or have particular insight into their thinking, I also welcome corrections.

    I’m refraining from comment or conclusion at this point, but stay tuned for a future post.

  • Woodwind trill technique

    Ideally, a trill is done with one finger, and preferably a finger that is nimble and independent, like an index or middle finger:

    flute bassoon clarinet

    In many cases that isn’t possible. When two fingers (or more!) are needed, it’s best if they can be fingers of the same hand, moving in the same direction (moving down onto keys/holes simultaneously).

    flute clarinet saxophone

    If the most obvious trill fingering involves more than one finger, try moving them each individually and see if you can produce something that works. If the pitch of the trilled note isn’t quite right, many woodwind players lean toward a sharper upper note rather than a flatter one.

    There are good fingering charts available online and in print that offer possible trill fingerings for when common/standard/obvious fingerings don’t work. If you find you need to invent a fingering, a good starting point is to finger the lower note on your instrument, and see what holes there are that you could open with a finger or two to possibly produce the upper note. Try each of them, and some combinations, until hopefully you find one that produces the right pitch. If you have a good understanding of your instrument’s registers, you may also find that you can borrow fingerings for one or both notes from other registers.

    Sometimes the tone, pitch, or response of the trill fingering isn’t good when you sustain it as an individual note, but will work acceptably in the context of a trill.

    The two notes of the trill should be about equally balanced, so that if you were to record it and slow it down you would hear that the individual notes of the trill are equal in duration and volume. Trills should also fit volume-wise into the context of the musical phrase; use strong and consistent breath support, as though you were playing a single long note.

    Trill speed is an artistic decision. Generally trills should be fast enough to give the impression of an effect applied to a single note, rather than a sequence of separate notes. They usually shouldn’t be so fast as to sound jarring or unnatural. The speed of the trill can change for musical effect, and when it does it usually starts slower and accelerates. The best way to learn appropriate trill speeds is by listening to great performances and recordings.

  • Doubling reed tip from Lawrie Bloom

    Lawrie Bloom, solo bass clarinetist of the Chicago Symphony Orchestra, starts this video talking about his reed break-in process, but spends some time toward the end (start at about 2:45 to cut to the chase) talking about his strategy for doubling clarinet and bass clarinet in a symphonic setting.

    Mr. Bloom recommends using slightly softer reeds than usual to compensate for the fact that the reeds will be somewhat drier than optimal, and using a mouthpiece cap whenever possible. Read More “Doubling reed tip from Lawrie Bloom”

  • Saxophone low notes

    Disclosure: As an Amazon Associate I earn from qualifying purchases, at no cost to you.

    The saxophone’s lowest notes can be notoriously unresponsive. This is partly due to the instrument’s acoustics, particularly its fairly extreme conical bore. (For technical details, see for example Acoustics of Musical Instruments by Chaigne and Kergomard, section 7.4.6.1.) The oboe and bassoon, whose bores are conical but not to such an extreme, have this problem to a lesser extent, and the tips that follow apply to those instruments as well.

    For the best chance at successful low notes you need:

    • A well-adjusted, high-quality instrument. Even a small leak anywhere on the saxophone makes the lowest notes more difficult. And the best-designed and most meticulously-made instruments help to minimize the difficulties of the low range.
    • A good mouthpiece and reed combination. This may involve tradeoffs: a mouthpiece/reed combination that really improves the low register may, for example, make the highest notes more difficult. Since mouthpieces and reeds vary in so many ways it’s hard to make reliable generalizations, but often I find that a wider tip opening with a softer reed tend to favor the low register more (and the high register less).
    • Good, stable fundamentals of saxophone technique. Breath support, voicing, articulation, and embouchure (let’s include jaw position in embouchure here) should be properly set, and shouldn’t change for the low register. If you find that you need to increase breath support, lower your voicing, change your embouchure or tonguing, or open your jaw to make the low notes succeed, then you should probably already be doing those things, in every register. Don’t make the low notes even harder by creating a moving target.

    To expand on that last point a little, if you find that your low notes need a little extra help, then a small alteration to your voicing is the right way to provide it. But know the tradeoffs: lowering your voicing as you approach the low register affects pitch and tone, besides creating instability in your tone production technique. Manage these concerns by aiming for the smallest possible change.

    Practice smart. No shortcuts!

  • Stop teaching clarinet and saxophone embouchures like this

    As a ten-year-old beginning saxophonist, I was taught to form an embouchure like this:

    • Put your top teeth on the mouthpiece
    • Let your lower lip sort of roll or squish over your lower teeth
    • Close your mouth

    That’s how I played for years. As I advanced and started to practice more, I would sometimes hurt the inside of my lower lip, drawing blood or forming blisters or scar tissue. I considered this a badge of honor: I practiced until I bled.

    But I don’t play that way anymore, nor do I teach students that way. I made an important change to my embouchure that lets me play for extended periods pain- and blood-free, while sounding better and having more control.

    The problem with the lower-lip-over-the-teeth approach is that it sets the lower lip up to serve as a sacrificial cushion, to protect the reed from the lower teeth. Sure, you can just tell your students to “stop biting,” but if you’re teaching them an embouchure that’s based on biting, then good luck.

    It’s more useful to think of the embouchure this way:

    • Put your top teeth on the mouthpiece
    • Let your jaw hang open a bit, so your lower teeth stay clear of the reed
    • Keep your jaw open, and allow your lips to close around the mouthpiece and reed.

    This approach makes sure the lips are used to form the embouchure, not the jaw. It improves tone, response, dynamic range, and more, and virtually eliminates lower lip pain.

    Left: jaw-formed clarinet embouchure. Right: lip-formed clarinet embouchure.

    If you are used to a jaw-formed embouchure concept, you might find that switching to the lip-formed embouchure leaves you feeling like you’ve lost some control of pitch and tone. If so, double-check your breath support; with the jaw out of the way you will need to depend on those support muscles more for stability.

    Don’t play through pain—use a better approach.

  • Trevor Wye’s “Flexibility I” flute exercise

    One of my favorite flute warmups is “Flexibility–I (after Sousseman)” from Trevor Wye’s Tone book. (Just buy the whole omnibus edition and thank me later.) This exercise is value-packed and meticulously thought out, and leads inevitably to some fundamental truths about flute playing.

    The exercise is slurred arpeggiated figures, like this:

    wye-1

    As you might expect, the figure gradually expands to larger intervals and notes in the third octave. It’s challenging to make the intervals smooth and accurate, but especially so if your approach to flute tone production is based on unclear or faulty pedagogical concepts. Wye provides some very crucial advice that is key to getting the most out of the etude, and to developing a solid approach to tone production.

    Wye suggests first playing the etude omitting the highest notes, and dynamically shaping the figures as follows:

    wye-2

    The forte dynamic on the lowest notes demands a low, open voicing and strong breath support, feeding into an aperture that is “focused” (small). The dynamic shape, stretched mostly across a single note (B-flat here), also requires the aperture to be agile and flexible, opening slightly for the loudest notes and closing slightly as the volume decreases.

    The next step is to “work up” to the high note, “so that it sounds softly, but not flat:”

    wye-3

    There is a lot going on here. The aperture has to continue to move flexibly in order to produce the dynamic effect. Voicing has to be low and open to make the low notes full and responsive. Breath support has to remain powerful and steady to keep the pitch buoyed up. And something has to happen to produce the register change.

    Many flute teachers suggest making the aperture smaller to achieve the higher registers, but this ties register to dynamics—the larger aperture makes the low notes loud, and the small aperture makes the high notes soft. Others suggest something like increasing air pressure or using “faster” air. This can be accomplished by increasing breath support and/or by using a higher voicing; changing these has a destabilizing and register-bound effect on pitch and tone. It also creates the opposite dynamic problem from aperture-based register changes: the higher notes are always loud, and the low notes are always soft.

    The most effective approach is to allow the embouchure to push forward for notes in the upper registers, and to relax back for lower registers. This allows breath support, voicing, and aperture to function separately, and intonation, tone, and dynamics to be manipulated independently. The Wye exercise demands all of this from the flutist.

    This is a great exercise to incorporate into a daily warmup. I especially like it for its coverage of several flute tone production concepts, since doubling on several instruments means I don’t have as much time to devote to the flute as I would like. Work on it slowly and deliberately—as Mr. Wye points out, “this may take time.”

6 Comments

  1. An interesting little piece, Bret. Personally, I never use the ‘one plus one’ fingering for e-flat, as it’s dreadfully out of tune and it requires movements of both hands on both the upper and lower joints of the instrument at the same time. I do use that fingering as a higher register b-flat, though, but only with certain arpeggios that are very fast.

  2. Interesting, Bret, to hear that this useful key has fallen into disuse or out of favor by clarinetists. I was taught this “sliver” fingering early on by my teacher Frederick Westphal, who introduced it in private lessons and in beginning woodwinds classes; and I have told students about its values and uses all my career. (Westphal also advocated the use of the Ring Key over the LH third finger hole, which is not found on most beginner clarinets, but it very useful. )

  3. I’ve generally considered the sliver fingering to be the default fingering for Eb/Eb on clarinet for a couple reasons.

    1. It keeps the motion in one hand for certain scalar patterns that you’re likely to see in many of the common key signatures.

    1. The intonation is generally a little more consistent than the side fingering. The thickness of the cork on the spatula of SK1 determines the opening of the key, and is regulated by the position of a small post on the lower joint. Since cork tends to settle over time, the opening of side Eb/Bb will continue to get wider as this happens. It also varies depending on how well you line up the bridge keys between the two joints. I would be willing to bet that most of you will find your side fingering to be a 5 – 10 cents higher than the sliver fingering. It will probably be more out of tune in the upper register due to the way that how the tone hole lattice reacts to the harmonic series.

  4. I use the L sliver key more on bass clarinet than soprano.

    It is more comfortable in the hand and more often helpful in physical terms because of the size of the instrument.

    I did not use on soprano clarinet until undergrad for 3rds in G-flat(F#).

  5. I have always used the chromatic eb key, but…..I am currently doubling on Eb clarinet (West Side Story, followed by a run of Assassins in October) a lot and Hadcock tells of removing the left sliver from his Eflat clarinet….and frankly, as tight as the keys are, I don’t know I use it on that instrument.

    Comments on removing from the eefer?
